8000l/h 10m3/h 7m3/h reverse osmosis RO water purification system

Industrial Ro System Plant

Home Product Center Industrial Ro System Plant

8000l/h 10m3/h 7m3/h reverse osmosis RO water purification system

Quick Details
Product name:deionized water machine
After-sales Service Provided:Free spare parts, Online support
Place of Origin:Guangdong, China
Condition:New
Power:2.95kw
Size:2500X1900X700mm
Weight:800KG
Material:wooden case or customeraized
Applicable Industries:Hotels, Farms, Retail, Printing Shops, Food & Beverage Shops
After Warranty Service:Video technical support, Spare parts, Field maintenance and repair service
production capacity:7m3/h,8m3/h,10m3/h
desalination rate:≥97%
Usage:drinking water purifier plant
voltage:220V/380V
recovery rate:50%-75%
warranty:1 year
pump:Nanfang CNP




Description



8000l/h 10m3/h 7m3/h reverse osmosis RO water purification system
Quick Details
Product name:deionized water machine
After-sales Service Provided:Free spare parts, Online support
Place of Origin:Guangdong, China
Condition:New
Power:2.95kw
Size:2500X1900X700mm
Weight:800KG
Material:wooden case or customeraized
Applicable Industries:Hotels, Farms, Retail, Printing Shops, Food & Beverage Shops
After Warranty Service:Video technical support, Spare parts, Field maintenance and repair service
production capacity:7m3/h,8m3/h,10m3/h
desalination rate:≥97%
Usage:drinking water purifier plant
voltage:220V/380V
recovery rate:50%-75%
warranty:1 year
pump:Nanfang CNP

Reverse osmosis system
Reverse osmosis process uses semi permeable spiral wound membranes to separate and remove dissolved solids, organic, pyrogens, sub micron colloidal matter and bacteria from water. Feed water isdelivered under a pressure of approximately 16 kg/cm2 through reverse osmosis membranes. Waterpermeates the minute pores of the membrane and is delivered as purified water. Impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens, and 99% bacterials in the feed water.
Flow Chart
raw water - raw water tank - raw water pump - sand filter - carbon filter - softener (optional) - security filter - high pressure pump - reverse osmosis system - pure water tank - UV sterilizer / ozone generator (optional) - water supply points
